Accessible PMR Sanitary Module – WC & Basin
The Accessible PMR Sanitary Module provides a compact, purpose-designed bathroom space for sites that need accessible amenities without constructing a permanent building. Its wide entrance, adapted WC and basin, support hardware and emergency lighting make it suited to workplaces, events, public facilities, depots, construction projects and other temporary or semi-permanent applications.
The module uses a galvanised steel frame with insulated sandwich panels and a reinforced cement-board floor finished in PVC. Its modest footprint makes it easier to position where a full-size ablution container would be unnecessary or impractical.
Accessibility & Sanitary Features
Accessible ceramic WC
Accessible ceramic basin approximately 600 × 510 mm
Wide 1,040 × 2,200 mm entrance door with approximately 900 mm clear passage
Support bar and clinical-style lever handle
Tilt window with protective bars and obscure glazing
Single-point water inlet and grouped waste outlet
Emergency light above the entrance
Optional aluminium access ramp and platform
Technical Specifications
Specification | Details |
External Height | 2,390 mm |
Internal Height | 2,200 mm |
Width | 2,300 mm |
Depth | 2,420 mm |
Structure | Galvanised and coated steel, approx. 1.5 mm |
Frame Colour | Light grey RAL 9002 |
Roof Profile | 154 mm high with four lifting points |
Base Profile | 80 mm high |
Walls | 40 mm rigid polyurethane sandwich panels |
Roof | 30 mm rigid polyurethane sandwich panels with galvanised corrugated outer sheet |
Floor | 16 mm cement-board with PVC covering |
Door | 1,040 × 2,200 mm; approx. 900 mm clear opening |
Window | 1,040 × 580 mm tilt window with bars and obscure glazing |
Heating | 1 × 1,000 W convector in source configuration |
Lighting | 1 × 7.5 W LED fitting plus emergency light |
Electrical | Distribution board and exterior connection box; final Australian compliance to be confirmed |
Optional Upgrades
1.5 m aluminium access ramp
2.42 m aluminium access platform
Hot-water service to basin
Double glazing
Reinforced skid/base options
Heavy-duty PVC, timber-look or tiled floor finish
Alternative wall panel specifications
Additional power outlets
90 m³/h extraction fan
Australian Installation Note
Final plumbing, electrical connection, access geometry and statutory accessibility requirements should be checked for the intended Australian site and use. Connection work should be completed by appropriately licensed trades.
